Product Description
206 high pressure Union
An O-ring is installed on the sealing surface of the male joint to make the sealing more tight. The available models are butt welded sch.40.
Recommended for manifold and piping connections, negative pressure service and corrosive service.
206 type 2000psi nscwp, test pressure 3000psi, blue nut, grey part.
|
Nominal pipe size |
Total length |
Nut radius |
Material science |
Weight |
|||||
|
Nut |
Spare parts |
||||||||
|
In |
mm |
In |
mm |
In |
mm |
|
|
Ibs |
kgs |
|
1 |
25.4 |
211/16 |
68.3 |
115/16 |
49.2 |
SC/SF |
CDB/SF |
1.75 |
0.8 |
|
11/2 |
38.1 |
27/8 |
73.0 |
23/8 |
60.3 |
SF |
SF |
2.37 |
1.1 |
|
2 |
50.8 |
35/16 |
84.1 |
229/32 |
73.8 |
SF |
SF |
5.25 |
2.4 |
|
21/2 |
63.5 |
41/16 |
103.2 |
311/16 |
93.7 |
SF |
SF |
10.0 |
4.5 |
|
3 |
76.2 |
43/8 |
111.1 |
37/8 |
98.4 |
SF |
SF |
15.25 |
6.9 |
|
4 |
101.6 |
413/16 |
122.2 |
5 |
127.0 |
SF |
SF |
20.0 |
9.1 |
|
6 |
152.4 |
65/8 |
168.3 |
67/16 |
163.5 |
SF |
SF |
44.5 |
20.2 |
|
8 |
203.2 |
71/4 |
184.2 |
711/16 |
195.3 |
SF |
SF |
61.0 |
27.7 |
