Product Description
1002 high pressure Union
Equipped with elastic nitrile rubber seal
It is recommended for cementing, fracturing, acidizing, testing, plugging and killing pipelines.
Designed for high voltage systems, including on-board systems. It can also be used as non pressure sealing Union. Use to weld sch.160 or Xxh.
1002 10000psi nscwp, test pressure 15000psi, red nut, blue part.
|
Nominal pipe size |
Total length |
Taper hole |
Nut radius |
Material science |
Weight |
||||||
|
Nut |
Spare parts |
||||||||||
|
In |
mm |
In |
mm |
In |
mm |
In |
mm |
|
|
Ibs |
kgs |
|
1 |
25.4 |
31/2 |
88.9 |
1/4 |
6.4 |
21/4 |
57.2 |
SF |
SF |
3.5 |
1.6 |
|
2 |
50.8 |
53/16 |
131.8 |
1/4 |
6.4 |
311/16 |
93.7 |
SF |
SF |
13.25 |
5.9 |
|
3 |
76.2 |
63/8 |
161.9 |
3/8 |
9.5 |
43/8 |
117.5 |
SF |
SF |
21.0 |
9.5 |
|
4 |
101.6 |
81/16 |
204.8 |
3/8 |
9.5 |
51/4 |
133.4 |
SF |
SF |
39.5 |
17.92 |
