Product Description
602 high pressure Union
Equipped with elastic nitrile rubber sealing ring, used to seal and protect the Union steel to steel matching.
It is recommended for manifold pipeline connection, vehicle and mud transportation, and can be used for non pressure sealing Union. Use butt welding sch.80.
602 6000PSI nscwp, test pressure 9000psi, black nut, orange part.
|
Nominal pipe size |
Total length |
Taper hole |
Nut radius |
Material science |
Weight |
||||||
|
Nut |
Spare parts |
||||||||||
|
In |
mm |
In |
mm |
In |
mm |
In |
mm |
|
|
Ibs |
kgs |
|
1 |
25.4 |
317/32 |
89.7 |
1/4 |
6.4 |
25/16 |
58.75 |
SF |
SF |
3.5 |
1.6 |
|
2 |
50.8 |
51/4 |
133.3 |
1/4 |
6.4 |
39/16 |
90.5 |
SF |
SF |
13.25 |
5.9 |
|
3 |
76.2 |
63/8 |
161.92 |
3/8 |
9.5 |
45/8 |
117.5 |
SF |
SF |
21.0 |
9.5 |
|
4 |
101.6 |
81/16 |
208.0 |
3/8 |
9.5 |
51/4 |
133.4 |
SF |
SF |
33.0 |
15.0 |
