1003 high pressure Union
1003 high pressure Union
The Union has a spherical seat, which can provide 71 / 2 degrees off center deflection or angle adjustment. The total deflection capacity is 15 degrees.
In addition to the combination of steel and steel, NBR O-type environmental protection certifies the air tightness of connection at any skew position
It is recommended for high pressure pipeline connection which cannot be timed. It can be used in air, water, oil, mud or gas.
1003 10000 psi nscwp (7500psi nscwp, 4in, 5in), black nut, green parts.
|
Nominal pipe size |
Total length |
Taper hole |
Nut radius |
Material science |
Weight |
|||||
|
Nut |
Spare parts |
|||||||||
|
In |
mm |
|
In |
mm |
In |
mm |
|
|
Ibs |
kgs |
|
3 |
76.2 |
NPT |
91/8 |
231.8 |
47/8 |
123.8 |
SC |
AS |
45.0 |
20.412 |
|
3 |
76.2 |
SCH160 |
87/8 |
225.4 |
47/8 |
123.8 |
SC |
AS |
47.5 |
21.546 |
|
3 |
76.2 |
XXHVY |
91/8 |
231.8 |
47/8 |
123.8 |
SC |
AS |
48.5 |
22.0 |
|
4 |
101.6 |
NPT |
1015/16 |
277.8 |
53/4 |
146.0 |
SC |
AS |
72.0 |
32.66 |
|
4 |
101.6 |
SCH160 |
1011/16 |
271.5 |
53/4 |
146.0 |
SC |
AS |
76.0 |
34.47 |
|
4 |
101.6 |
XXHVY |
1015/16 |
277.8 |
53/4 |
146.0 |
SC |
AS |
78.0 |
35.38 |
|
5 |
127 |
SCH160 |
103/4 |
273.1 |
53/4 |
146.0 |
SC |
AS |
74.0 |
33.57 |
|
5 |
127 |
XXHVY |
1015/16 |
277.8 |
53/4 |
146.0 |
SC |
AS |
76.5 |
34.8 |
