Product Description
2002 high pressure Union
The union is three available in 2-4 inches and is equipped with a replaceable elastomeric nitrile rubber seal ring combination in a stainless steel liner to provide complete extrusion protection in overpressure applications.
The detachable nut / sector ring / retainer ring design simplifies the removal of the nut from the pipe.
2002 20000 psi nscwp, test pressure 30000 psi, red nut, red parts.
|
Nominal pipe size |
Total length |
Taper hole |
Material science |
weight |
|||||
|
Nut |
Spare parts |
||||||||
|
In |
mm |
In |
mm |
In |
mm |
|
|
Ibs |
kgs |
|
2 |
50.8 |
73/8 |
187.32 |
311/16 |
93.66 |
SF |
AS |
22.5 |
10.21 |
|
3 |
76.2 |
95/8 |
244.5 |
47/8 |
123.825 |
SF |
AS |
48.0 |
21.77 |
|
4 |
101.6 |
81/2 |
215.9 |
6 |
152.4 |
SF |
AS |
76.0 |
34.47 |
